Stacker Tag Trailers

Unmatched Quality

Highly Customizable

18' - 34' Long

Stacker Tag Galleries

Browse the trailer galleries to discover ideas & configurations for your next trailer build!

View All Galleries

Option Gallery

Browse the option gallery to discover options that fit your needs!

Framed Opening to Attic with Fixed Ladder

Surface Mounted Airline Track On Lift Floor

Stainless Steel Rear Header & Post (Stacker) (Shown with Optioned Rear Spoiler)

Upgrade Light Mounted at 45 Degrees On Cove - Shown With STACKER COVE

aluminum transition flap from lift to attic

View More Options

Color Options

Choose a color and view it on the trailer.

*FH - This designates a thickness that is available as Full Hard only. A full hard metal aluminum cannot be bent at front or rear corners without cracking, additional upgrades may be required with a FH color selected. FH colors can not be used on cabinets.
Additional charges may apply for certain colors & thicknesses. Colors available are subject to change without notice.

Colors	.040	.050
Polar White		FH
Silver Frost (Metallic)
Black		FH
Matte Black
Med Charcoal Gray (Metallic)
Light Pewter (Metallic)
Metallic Gray	FH	FH
Sportsman Gray
Victory Red

Premium Colors	.040	.050
Royal Blue
Penske Yellow	FH

Standard Features

See what features come standard on our Stacker Trailers.

Full Perimeter Aluminum Frame
All Tube Aluminum Construction
Triple Tube A-Frame Tongue
(3) Dexter Torsion Axles W/ Electric Brakes On All Axles (Except 18' Tag Stacker Has Tandem Axles)
Breakaway Battery Kit
7-Way Trailer Plug
2 5/16" Ball Coupler
Safety Chains W/ Storage Loops
Single Post Hydraulic Jack
16" O/C Floor Crossmembers
16" O/C Wall & Ceiling Studs
Smooth Aluminum Wheel Boxes W/ Rounded Edge
Triple Axle Design W/ Individual Fenderettes (Except 18' Tag Stacker W/ Tandem Axles)
Tires W/ Aluminum Wheels

Extruded Aluminum Floor
Extruded Aluminum Ramp Door
One-Piece Aluminum Transition Flap
(6) 12V LED Dome Lights W/ Switch
.030 Screwless Aluminum Walls & Ceiling
10' Standard Interior Height
(8) 5000# Recessed D-Rings (4 - Main Floor; 4 - Lift)
Interior Beavertail - (Except 18' & 20' Tag Stackers) - Varies By Length

.040 Aluminum Skin
Screwless/Rivetless Aluminum Exterior
One Piece Aluminum Roof
Arched & Trussed Walk-On Service Roof (Deleted W/ Full Height Option)
4" Upper & 6" Lower Rub Rail
Clear Anodized Trim Package Including Stoneguard
LED Premium Clearance Lights
Dual LED Slimline Tail Lights
LED Slimline Backup Lights
36" ATP Stoneguard
Slideout Aluminum Step - Non-Slip
36" 405 Series Entrance Door
Polished Cast Aluminum Corners
Stainless Steel #8 High Polish Front Verticals & Radius)
Rear Ramp Door W/ Gapless Continuous Hinge
Stainless Steel Rear Paddle Latches
Rear Caster Wheels - Pair

20A Motorbase Plug
45 Amp Converter Battery Charger
(2) 12V Deep Cycle Batteries W/ Vented Boxes
In Floor Battery Compartment
14' Aluminum Split Rail Lift (4000# Capacity)
ATP Finish On Lift Surface
Underside Of Lift Finished W/ .030 Aluminum
In-Floor Hydraulic Lift Pump
Rear Manual Stabilizer Jacks
Tongue Weight Scale
32" Removable Lift Ramps W/ Wall Storage

Design Layouts

Download & view prints by trailer size.

Pick A Size

Model	Flat Nose	2' Wedge Nose	4' Wedge Nose
8.5 x 22
8.5 x 24
8.5 x 26
8.5 x 28
8.5 x 30
8.5 x 32
8.5 x 34

Specifications

Select and download axle specifications.

Triple Axle

Model	6000 lbs	7000 lbs	8000 lbs
8.5 x 22
8.5 x 24
8.5 x 26
8.5 x 28
8.5 x 30
8.5 x 32
8.5 x 34

Factory Tours

inTech Trailers welcomes potential customers and interested parties to visit our facility for a tour of our manufacturing process.

Schedule Tour

Model		BSA8522TTA4
Overall	Length Box Width* Height**	26' .25"
		8'4"
		12' 1"
Interior	Length Width Height	21' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	6,000
		3
		18,000
		All Wheel
Tire	Size Load Range / Ply	ST235/80R16
		E / 10
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8522TTA5
Overall	Length Box Width* Height**	26' .25"
		8'4"
		12' 1"
Interior	Length Width Height	21' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	7,000
		3
		21,000
		All Wheel
Tire	Size Load Range / Ply	ST235/85R16
		G / 14
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8522TTA6
Overall	Length Box Width* Height**	26' .25"
		8'4"
		12' 1"
Interior	Length Width Height	21' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		81"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	8,000
		3
		24,000
		All Wheel
Tire	Size Load Range / Ply	LT215/75R17.5
		H / 16
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8524TTA4
Overall	Length Box Width* Height**	28' .25"
		8'4"
		12' 1"
Interior	Length Width Height	23' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	6,000
		3
		18,000
		All Wheel
Tire	Size Load Range / Ply	ST235/80R16
		E / 10
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8524TTA5
Overall	Length Box Width* Height**	28' .25"
		8'4"
		12' 1"
Interior	Length Width Height	23' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	7,000
		3
		21,000
		All Wheel
Tire	Size Load Range / Ply	ST235/85R16
		G / 14
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8524TTA6
Overall	Length Box Width* Height**	28' .25"
		8'4"
		12' 1"
Interior	Length Width Height	23' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		81"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	8,000
		3
		24,000
		All Wheel
Tire	Size Load Range / Ply	LT215/75R17.5
		H / 16
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8526TTA4
Overall	Length Box Width* Height**	30' .25"
		8'4"
		12' 1"
Interior	Length Width Height	25' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	6,000
		3
		18,000
		All Wheel
Tire	Size Load Range / Ply	ST235/80R16
		E / 10
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8526TTA5
Overall	Length Box Width* Height**	30' .25"
		8'4"
		12' 1"
Interior	Length Width Height	25' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	7,000
		3
		21,000
		All Wheel
Tire	Size Load Range / Ply	ST235/85R16
		G / 14
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8526TTA6
Overall	Length Box Width* Height**	30' .25"
		8'4"
		12' 1"
Interior	Length Width Height	25' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		81"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	8,000
		3
		24,000
		All Wheel
Tire	Size Load Range / Ply	LT215/75R17.5
		H / 16
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8528TTA4
Overall	Length Box Width* Height**	32' .25"
		8'4"
		12' 1"
Interior	Length Width Height	27' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	6,000
		3
		18,000
		All Wheel
Tire	Size Load Range / Ply	ST235/80R16
		E / 10
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8528TTA5
Overall	Length Box Width* Height**	32' .25"
		8'4"
		12' 1"
Interior	Length Width Height	27' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	7,000
		3
		21,000
		All Wheel
Tire	Size Load Range / Ply	ST235/85R16
		G / 14
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8528TTA6
Overall	Length Box Width* Height**	32' .25"
		8'4"
		12' 1"
Interior	Length Width Height	27' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		81"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	8,000
		3
		24,000
		All Wheel
Tire	Size Load Range / Ply	LT215/75R17.5
		H / 16
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8530TTA4
Overall	Length Box Width* Height**	34' .25"
		8'4"
		12' 1"
Interior	Length Width Height	29' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	6,000
		3
		18,000
		All Wheel
Tire	Size Load Range / Ply	ST235/80R16
		E / 10
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8530TTA5
Overall	Length Box Width* Height**	34' .25"
		8'4"
		12' 1"
Interior	Length Width Height	29' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	7,000
		3
		21,000
		All Wheel
Tire	Size Load Range / Ply	ST235/85R16
		G / 14
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8530TTA6
Overall	Length Box Width* Height**	34' .25"
		8'4"
		12' 1"
Interior	Length Width Height	29' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		81"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	8,000
		3
		24,000
		All Wheel
Tire	Size Load Range / Ply	LT215/75R17.5
		H / 16
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8532TTA4
Overall	Length Box Width* Height**	36' .25"
		8'4"
		12' 1"
Interior	Length Width Height	31' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	6,000
		3
		18,000
		All Wheel
Tire	Size Load Range / Ply	ST235/80R16
		E / 10
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8532TTA5
Overall	Length Box Width* Height**	36' .25"
		8'4"
		12' 1"
Interior	Length Width Height	31' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		82"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	7,000
		3
		21,000
		All Wheel
Tire	Size Load Range / Ply	ST235/85R16
		G / 14
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

Model		BSA8532TTA6
Overall	Length Box Width* Height**	36' .25"
		8'4"
		12' 1"
Interior	Length Width Height	31' 11"
		8' 2"
		120
Deck Height		22"
Ground Clearance		13"
Rear Ramp Width x Height		90" x 84"
Width Between Wheel Wells		81"
Dexter Torsion Axle	Rating Quantity GVWR Brakes	8,000
		3
		24,000
		All Wheel
Tire	Size Load Range / Ply	LT215/75R17.5
		H / 16
Hitch	Ball Size Height to Top	2 5/16"
		21"
Studs	Wall Floor Ceiling	16" on Center
		16" on Center
		16" on Center
Beavertail Length - Standard 3" Drop		3'

RV Home

Factory Tours

Customer Support

Adventure Club

Locate Dealer

Stacker Tag Trailers

Unmatched Quality

Highly Customizable

18' - 34' Long

Stacker Tag Galleries

Option Gallery

Color Options

Standard Features

Chassis

Interior

Exterior

Stacker Features

Design Layouts

Pick A Size

Specifications

Triple Axle

Factory Tours

How Can We Help You?

Options & Packages

Customer Portal

Factory Tours

Customer Support

Marketplace

Ready To Buy?
